The EL817 Phototransistor Photocoupler series of devices each consist of an infrared emitting diodes, optically coupled to a phototransistor detector. They are packaged in a 4-pin DIP package and available in wide - lead spacing and SMD option.EL817 series of devices are Photo transistor based photo..

The TIP31 is a standard type of NPN bipolar junction transistor used for medium power applications. TIP31 transistors are designated as TIP31A, TIP31B, and TIP31 to indicate increasing collector-base and collector-emitter breakdown voltage ratings. The TIP31 is packaged in a TO-220 case.Features of ..

The TIP127 is a PNP Epitaxial Darlington Transistor. Mainly used for Medium Power Linear Switching Applications and Complements to TIP120/121/122.Features of TIP 127Collector-Emitter Volt (Vceo): 100V.Collector-Base Volt (Vcbo): 100V.Collector Current (Ic): 5.0A.hfe: 1,000 @ 500mA.Power Dissipation ..

A C945 transistor is a type of NPN bipolar junction transistor. Circuits where a low-current, high-speed transistor is required will employ a transistor such as C945 transistor. Circuits such as a small-signal amplifier or a high-speed switching circuit might employ one or more C945 transistors.Feat..

Dual H-Bridge Power Transistor Motor Driver Arduino Board is a simple motor driver used to drive high power dc motor which is both the combination of two NPN & PNP (TIP-122 & TIP-127) transistors to operate dual motor at a time in bidirectional.Features of Dual H-Bridge Power Transistor Moto..

The TIP50 NPN High Voltage Transistor is silicon Multi epitaxial NPN Planar transistors mounted in Jedec TO-220 plastic package. It is intended for use in linear and switching applicationsTIP50 Key Features250 V to 400 V (Min) — VCEO(sus)1 A Rated Collector CurrentPopular TO–220 Plastic PackageType ..

2SB1237 PNP General Purpose Transistor is designed for the Low saturation voltage. 2SB1237 complementary to 2SD1664.FeaturesCollector-Emitter Volt (Vceo): 32VCollector-Base Volt (Vcbo): 40VCollector Current (Ic): 1.0Ahfe: 82-390 @ 100mAPower Dissipation (Ptot): 1000mWCurrent-Gain-Bandwidth (ftotal):..

The 2SB544 is a PNP general-purpose transistor commonly used in a variety of electronic applications. This transistor is designed to handle moderate power and voltage levels, making it suitable for amplification, switching, and signal processing circuits.FeaturesCollector-Emitter Volt (Vceo): 25VCol..

2SA1309A PNP General Purpose Transistor is designed for low-frequency amplification applications. 2SA1309A is complementary to 2SC3311A.FeaturesCollector-Emitter Volt (Vceo): 50VCollector-Base Volt (Vcbo): 60VCollector Current (Ic): 0.1Ahfe: 160-460 @ 2mAPower Dissipation (Ptot): 300mWCurrent-Gain-B..

2SA1175 PNP General Purpose Transistor is designed for the driver stage of AF amplifier applications. 2SA1175 is complementary to 2SC2785.FeaturesCollector-Emitter Volt (Vceo): 50VCollector-Base Volt (Vcbo): 60VCollector Current (Ic): 0.1Ahfe: 110-600 @ 1mAPower Dissipation (Ptot): 250mWCurrent-Gain..

FeaturesDrain-Source Volt (Vds): 400VDrain-Gate Volt (Vdg): 400VGate-Source Volt (Vgs): 20VDrain Current (Id): 10APower Dissipation (Ptot): 125WType: N-Channel..

The 2SA1048 is a PNP general-purpose transistor that is commonly available in packs of five. This transistor is designed to handle moderate power and voltage levels in a variety of applications. It belongs to the A1048 series of transistors and can be used in amplification, switching, and signal pro..

2SA1015 PNP General Purpose Transistor is designed for the driver stage amplifier applications. 2SA1015 is complementary to 2SC1815.FeaturesCollector-Emitter Volt (Vceo): 50VCollector-Base Volt (Vcbo): 50VCollector Current (Ic): 0.15Ahfe: 70-400 @ 2mAPower Dissipation (Ptot): 400mWCurrent-Gain-Bandw..

2SA992 PNP General Purpose Transistor is best for use as the middle range amplifier in Hi-Fi stereo control amplifiers; power amplifiers. 2SA992 is Complementary to 2SC1845.FeaturesCollector-Emitter Volt (Vceo): 120VCollector-Base Volt (Vcbo): 120VCollector Current (Ic): 0.05Ahfe: 200-800 @ 1mAPower..

The 2SA950 is a PNP general-purpose transistor that is commonly available in packs of five. This transistor is designed for various applications that require amplification, switching, and signal processing.FeaturesCollector-Emitter Volt (Vceo): 30VCollector-Base Volt (Vcbo): 35VCollector Current (Ic..

2SA933 is PNP General Purpose Transistor having linear Hybrid parameter forward current gain (hfe). 2SA933 is complementary to 2SC2412K.FeaturesCollector-Emitter Volt (Vceo): 50VCollector-Base Volt (Vcbo): 60VCollector Current (Ic): 0.15Ahfe: 120-560 @ 1mAPower Dissipation (Ptot): 300mWCurrent-Gain-..

2SA950 PNP Audio Amplifier Transistor is designed for Low-frequency amplifier and Complementary pair with 2SC1213.FeaturesCollector-Emitter Volt (Vceo): 35VCollector-Base Volt (Vcbo): 35VCollector Current (Ic): 0.5Ahfe: 60-320 @ 10mAPower Dissipation (Ptot): 400mWType: PNP..

2N6517 NPN High-Voltage TransistorFeaturesCollector-Emitter Volt (Vceo): 350VCollector-Base Volt (Vcbo): 350VCollector Current (Ic): 0.5Ahfe: 30-200 @ 30mAPower Dissipation (Ptot): 625mWCurrent-Gain-Bandwidth (ftotal): 40MHzType: NPN..

FeaturesCollector-Emitter Volt (Vceo): 160VCollector-Base Volt (Vcbo): 180VCollector Current (Ic): 0.6Ahfe: 80-250 @ 10mAPower Dissipation (Ptot): 625mWCurrent-Gain-Bandwidth (ftotal): 300MHzType: NPN..

FeaturesCollector-Emitter Volt (Vceo): 300VCollector-Base Volt (Vcbo): 350VCollector Current (Ic): 1.0Ahfe: 30-120 @ 50mAPower Dissipation (Ptot): 1000mWCurrent-Gain-Bandwidth (ftotal): 15MHzType: NPN..
